Mem09005b Perform Basic Engineering Drafting

Author: Warren Blackadder
Publisher: Lulu.com
Category: Engineering: General
Age Group: 15+
Book Format: Paperback

This unit covers producing drawings to Australian Standard 1100 or equivalent where the critical dimensions and associated tolerances for components and/or materials are selected from supplier/manufacturers' catalogues using design specifications.



Manual drafting or drawing equipment is used or where a CAD (Computer Aided Design) system is used, Unit MEM09009C (Create 2D drawings using computer aided design system) and/or Unit MEM09010C (Create 3D models using computer aided design system) should also be considered.



A CD containing the skill practice drawing templates can be obtained by contacting blackline@bigpond.net.au for $10 plus postage.

(BK-9781291588910)

SKU BK-9781291588910
Barcode # 9781291588910
Brand Lulu.com
Artist / Author Warren Blackadder
Shipping Weight 0.2700kg
Shipping Width 0.210m
Shipping Height 0.010m
Shipping Length 0.300m
Assembled Length 29.700m
Assembled Height 0.600m
Assembled Width 21.000m
Type Paperback
